Gasoline inverter generator 1000W/220V/50-60Hz

Short Description:

Place of Origin:Fujian, China
Brand Name:OEM
Model Number:NH1000
Rated Voltage:230
Rated Current:4.34A
Engine model:1E47F
Engine type:2-stroke reed valve, forced air cooled gasoline engine
Fuel capacity:2.2L
Fuel Consumption ( L / H ):0.83
Continuous Running Time(Hrs):3
Starting system:Recoil starter
Packing size L*W*H (mm):334*262*330
Net / Gross weight (kg):11.7 / 12.7
QTY 20′GP/40′HQ(sets):1030 / 2150

Product Detail

Product Tags

Technical Date:

GENSET Model YK1000i / YK950i-M3
Rated frequency (Hz) 50 / 60 Engine model 1E47F (2.2HP)
Rated voltage (V) 230 Engine type 1 cylinder, 2-stroke
Rated current (A) 4.34 Displacement (cc) 69
Rated speed (r/min) 2800-3400 Fuel capacity (L) 2
Rated output (W) 0-1000 Cont. running time (Hrs.) 3
Max. output (W) 1100 Starting system Recoil starter
Phase number Single Packing size L×W×H (mm) 334×262×330
Alternator type 100% copper winding,Rare earth permanent magnet alternator Net / Gross weight (kg) 12月13日
QTY 20’GP / 40’HQ (Sets) 1000 / 2160
 Features1   Features2  Features3  Features4  Features5
100% Copper Winding stator/RotorRare earth Permanent Magnet Alternator  Inverter Technology
Stable Output
A4 Paper Size
Weight only 12kg
2-Levels Adjustable Output

Lightweight design

Only 12KG, small and portable. It is the best choice for outdoors, household use,stores or emergency lighting.

Leading inverter technology

Built-in intelligent inverter system with overloaded , short-circuit,overvoltage ,under-voltage and thermal automatic protection,effectively extending the service life of generators.

Manual speed regulator

Low gear 500W, high gear 1000W, adjustable by manual according to the load demand.

DC output socket

12V DC output,5A max current,available for DC lighting and battery.(Optional: cigar lighter port/USB charger)

Gasoline Inverter Generator 800W/220V/50-60Hz-6

Technical Data:

GENSET Model NH800 NH1000
Rated Frequency(Hz) 50 50
Rated Voltage(V) 230 230
Rated Current(A) 3.47 4.34
Rated Engine Speed(RPM) 2400-300 2800-3400
Rated Output(W) 0-800 0-1000
Max.Output(W) 900 1100
DC Output 12V-3.0A(OPTION) 12V-5.0A(Option)
Phase Single
Packing size L*W*H(mm) 334*262*330
N.G./G.W.(kg) 11.7/12.7 12/13
Ref QTY/20'GP/40'HQ(sets) 1030/2200
Engine Model Name 1E45F 1E47F
Engine Model 2-strike reed valve,forced air cooled gasoline engine
Displacement(cc) 63 69
Fuel Tank Capacity(L) 2.2
FUEL Consumption(L/H) 0.62 0.83
Continuous Running Time(Hrs) 4 3
Starting System Recoil starter
Noise Level(dB/7M) 68 72

Genset Structure:

NH800 2-Stroke Inverter Gasoline Gensets consist of 3 main parts:

1.Engine: traditional 2-Stroke 950 Gasoline engine,Model 1E45F

2.Alternator:High efficiency rare earth permanent magnetic alternator,which is exclusive part made by ourselves.

3.Inverter: Inverter and the front panel integration,which is exclusive part made by ourselves.

4.Other parts:Fuel tank and side cover which are exclusive part made by ourselves.

 Features1 Features2  Features3
Engine stator/Rotor Inverter Front Panel Fuel Tank Side Cover
