Gasoline Inverter Generator 800W/220V/50-60Hz

Gasoline Inverter Generator 800W/220V/50-60Hz Featured Image
  • Gasoline Inverter Generator 800W/220V/50-60Hz
  • Gasoline Inverter Generator 800W/220V/50-60Hz

Short Description:

Fujian, China
Brand Name: OEM
Model Number:NH800
Rated Voltage:230
Rated Current:3.47A
Speed:2400-3000rpm
Frequency:50hz
Engine model:1E45F
Engine type:2-stroke reed valve, forced air cooled gasoline engine
Displacement:63cc
Fuel capacity:2.2L
Fuel Consumption ( L / H ):0.62
Continuous Running Time(Hrs):4
Starting system:Recoil starter
Packing size L*W*H (mm):334*262*330
Net / Gross weight (kg):11.7 / 12.7


Product Detail

Product Tags

Gasoline Inverter Generator 800W/220V/50-60Hz-5
Gasoline Inverter Generator 800W/220V/50-60Hz-6

Technical Data:

GENSET Model NH800 NH1000
Rated Frequency(Hz) 50 50
Rated Voltage(V) 230 230
Rated Current(A) 3.47 4.34
Rated Engine Speed(RPM) 2400-300 2800-3400
Rated Output(W) 0-800 0-1000
Max.Output(W) 900 1100
DC Output 12V-3.0A(OPTION) 12V-5.0A(Option)
Phase Single
Packing size L*W*H(mm) 334*262*330
N.G./G.W.(kg) 11.7/12.7 12月13日
Ref Qty/20'GP/40'HQ(sets) 1030/2200
Engine Model Name 1E45F 1E47F
Engine Model 2-strike reed valve,forced air cooled gasoline engine
Displacement(cc) 63 69
Fuel Tank Capacity(L) 2.2
FUEL Consumption(L/H) 0.62 0.83
Continuous Running Time(Hrs) 4 3
Starting System Recoil starter
Noise Level（dB/7M) 68 72

Genset Structure:

NH800 2-Stroke Inverter Gasoline Gensets consist of 3 main parts:

1.Engine: traditional 2-Stroke 950 Gasoline engine,Model 1E45F

2.Alternator:High efficiency rare earth permanent magnetic alternator,which is exclusive part made by ourselves.

3.Inverter: Inverter and the front panel integration,which is exclusive part made by ourselves.

4.Other parts：Fuel tank and side cover which are exclusive part made by ourselves.

Governor adjustion:

The inverter technology is applied to NH800 /NH1000,The speed of the genset can be adjusted according to the load,such as NH800/ NH1000 is designed as 2 level adjustable, high speed at 100% load,low speed at 50% load.For example, the speed of NH800 is designed to be 3000rpm at 100% load and 800w,2400rpm at 50% load and 400w.Thegenset tuns at low speed,its noise level, fuel consumption, engine and alternator heat dissipation are much better,the genset life time is extended. The end-user may adjust speed at different load level. Adjustable speed make thegenset more humanized and fuel saving.

Model Traditional 950 Gasoline Geneset NH800 Inverter Gasoline Genset Contrast Result
Picture  1
Rated Output 600W/210V 1E45 800W/200V 1E45 200W more
Rated Frequency 50Hz±5% 50Hz±5% Less frequency fluctuation
Volume 380*320*320cm 334*262*330cm 2/5 less in volume
N.W（kg) 17 11 6Kgs less in the weight
Ref.qty/40HQ（set) 1600 2200 600 sets more in container loading
Fuel Consumption 3000RPM,210V,600W,working condition 0.675/kw/H.L 3000RPM,220V,800W,working condition 0.478/KW/H.L 0.2L less in fuel consumption @KW/H
4
