| Model |
XGP40H |
XGP40H-2 |
XGP50H |
| FOB Fuzhou port,China |
|
|
|
| Delivery(mm） |
（1.5”）40*1 （1.0”）25*2 |
（1.5”）40*1 （1.0”）25*2 |
（2“）50 |
| Suction(mm） |
（1.5”）40*1 |
（1.5”）40*1 |
（2“）50 |
| Self-priming Time(s/4m) |
30 |
30 |
30 |
| Suction Head (m) |
8 |
8 |
8 |
| Max.Delivery Volume (m3/h) |
33 |
35 |
45 |
| Total Head (m) |
55 |
77.5 |
52 |
| Gasoline Engine Model |
170/E |
170/E |
170/E |
| Bore*stroke(mm*mm) |
70*54 |
70*54 |
70*54 |
| Displacement (cc) |
207 |
207 |
207 |
| Max. Power Output (hp) |
7 |
7 |
7 |
| Max. Output（kW） |
5.2kw |
5.2kw |
5.2kw |
| Rated Output（kW） |
4.2kw |
4.2kw |
4.2kw |
| Compression ratio |
8.5:1 |
8.5:1 |
8.5:1 |
| Gasoline Engine Type |
4-Stroke,OHV 25° inclined single cylinder , Air-cooled |
| Lube oil system |
Splash Type |
| Ignition System |
Non-contact transistorize ignition(TCI) |
| Starting System |
Recoil |
| Fuel Tank Capacity（L） |
3.6L |
3.6L |
3.6L |
| Lube oil capacity（L) |
0.6 |
0.6 |
0.6 |
| Fuel Consumption(g/kw/h) |
290 |
290 |
290 |
| Dimensions(L*W*H)(mm) |
525*405*475 |
525*405*475 |
525*405*475 |
| N.W/G.W kg |
25/27 |
26/28 |
26/28 |
| 20ft(set) |
279 |
279 |
279 |
