Small diesel engine power

Small diesel engine power Featured Image
  • Small diesel engine power
  • Small diesel engine power

Short Description:


  • Power range:: 4.0HP~9.0HP

    • Product Detail

    Product Tags

    Model XD170F(E) XD170FA(E) XD178F(E) XD178FA(E) XD186F(E) XD186FA(E)
    FOB Fuzhou port,China
    Diesel Engine Type Air-cooled, 4-stroke,Vertical,Single-cylinder,  Direct injection combustion.
    Bore*stroke(mm*mm) 70*55 70*57 78*62 78*64 86*70 86*72
    Displacement (cc) 211 219 296 306 406 418
    Governor System All-speed Type, Mechanical Governor
    Max. Power Output (hp) 4.0HP 4.0HP 6.0HP 6.0HP 9.0HP 9.0HP
    Max.Output（kW/rpm） 2.8/3000  3.1/3600 2.8/3000 3.1/3600 4.0/3000  4.4/3600 4.0/3000  4.4/3600 6.3/3000  6.9/3600 6.3/3000  6.9/3600
    Rated  Output（kW/rpm） 2.5/3000  2.8/3600 2.5/3000  2.8/3600 3.7/3000 4.0/3600 3.7/3000 4.0/3600 5.7/3000  6.3/3600 5.7/3000  6.3/3600
    Compression rate 20:01 20:01 20:01 20:01 19:01 19:01
    Ignition System Explode Ignition
    Lube oil system Pressure splash Type
    Fuel type 0#（Summer）10#（winter）35#（chill）
    Lube oil type SAE10W30( above CD grade ）
    Starting System Recoil or Electric
    Lube oil capacity （L) 0.75 0.75 1.1 1.1 1.65 1.65
    Fuel Consumption(g/kw/h)≤ 290/295 290/295 280/285 280/285 265/270 265/270
    Fuel Tank Capacity（L） 2.5 2.5 3.5 3.5 5.5 5.5
    Noise Level（7M)dB(A) 70 70 78 78 86 86
    Dimension(L*W*H)(mm) 425*385*465 425*385*465 470*460*520 470*460*520 520*475*560 520*475*560
    N./G.W Recoil/electric start (kg) 26/28  31/33 26/28   31/33 33/35  38/40 33/35  38/40 48/50  53/55 48/50  53/55
    20ft(set) 389 389 240 240 192 192
    Diesel Engine Model XD170F(E) XD170FA(E) XD178F(E) XD178FA(E) XD186F(E) XD186FA(E)
    Diesel Engine Type Air-cooled, 4-stroke,Vertical,Single-cylinder,  Direct injection combustion. Air-cooled, 4-stroke,Vertical,Single-cylinder,  Direct injection combustion. Air-cooled, 4-stroke,Vertical,Single-cylinder,  Direct injection combustion. Air-cooled, 4-stroke,Vertical,Single-cylinder,  Direct injection combustion. Air-cooled, 4-stroke,Vertical,Single-cylinder,  Direct injection combustion. Air-cooled, 4-stroke,Vertical,Single-cylinder,  Direct injection combustion.
    Bore*stroke(mm*mm) 70*55 70*57 78*62 78x64 80*70 86x72
    Displacement (cc) 211 219 296 306 406 418
    Governor System All-speed Type, Mechanical Governor All-speed Type, Mechanical Governor All-speed Type, Mechanical Governor All-speed Type, Mechanical Governor All-speed Type, Mechanical Governor All-speed Type, Mechanical Governor
    Max. Power Output (hp) 4.0HP 4.0HP 6.0HP 6.0HP 9.0HP 9.0HP
    Max.Output（kW/rpm） 2.8/3000  3.1/3600 2.8/3000 3.1/3600 4.0/3000  4.4/3600 4.0/3000  4.4/3600 6.5/3000  6.9/3600 6.5/3000  6.9/3600
    Rated  Output（kW/rpm） 2.5/3000  2.8/3600 2.5/3000  2.8/3600 3.7/3000 4.0/3600 3.7/3000 4.0/3600 5.7/3000  6.3/3600 5.7/3000  6.3/3600
    Lowest speed (r/min) 1800rpm 1800rpm 1800rpm 1800rpm 1800rpm 1800rpm
    Compression ratio 20:01 20:01 20:01 20:01 19:01 19:01
    Ignition System Explode Ignition Explode Ignition Explode Ignition Explode Ignition Explode Ignition Explode Ignition
    Lube oil system Pressure splash Type  Pressure splash Type  Pressure splash Type  Pressure splash Type Pressure splash Type  Pressure splash Type
    Fuel type 0#（Summer）10#（winter）35#（chill） 0#（Summer）10#（winter）35#（chill） 0#（Summer）10#（winter）35#（chill） 0#（Summer）10#（winter）35#（chill） 0#（Summer）10#（winter）35#（chill） 0#（Summer）10#（winter）35#（chill）
    Lube oil type SAE10W30( above CD grade ） SAE10W30( above CD grade ） SAE10W30( above CD grade ） SAE10W30( above CD grade ） SAE10W30( above CD grade ） SAE10W30( above CD grade ）
    Lube oil capacity （L) 0.75 0.75 1.1 1.1 1.65 1.65
    Starting System Recoil or Electric Recoil or Electric Recoil or Electric Recoil or Electric Recoil or Electric Recoil or Electric
    Fuel Consumption(g/kw/h)≤ 290/295 290/295 280/285 280/285 265/270 265/270
    Fuel Tank Capacity（L） 2.5 2.5 3.5 3.5 5.5 5.5
    Cont.Operating Hours 3.0/2.6 3.0/2.6 3.0/2.7 3.0/2.7 2.8/2.7 2.8/2.7
    Noise Level（7M)dB(A) 70 70 78 78 86 86
    Dimensions(L*W*H)(mm) 425*385*465 425*385*465 470*460*520 470*460*520 520*475*560 520*475*560
    N./G.W Recoil/electric start (kg) 26/28  31/33 26/28   31/33 33/35  38/40 33/35  38/40 48/50  53/55 48/50  53/55
    20ft(set) 389 389 240 240 192 192
