Gasoline engine 5-10kw

Gasoline engine 5-10kw Featured Image
  • Gasoline engine 5-10kw
  • Gasoline engine 5-10kw

Short Description:


Product Detail

Product Tags

MODEL ㅤ KG6500 KG7500 KG8500 KG9500 KG9800E KG10000E KG10500E
Generator Frequency(HZ) 50 50 50 50 50 50 50
Voltage(V) 220 220 220 220 220 220 220
Max. Power(KW) 5.5 6.5 7.5 8.5 9 9.5 10.5
Rated Power(KW) 5 6 7 8 8.5 9 10
DC Output 12V/8.3A 12V/8.3A 12V/8.3A 12V/8.3A 12V/8.3A 12V/8.3A 12V/8.3A
Power Factor cos 1 1 1 1 1 1 1
Engine Model KG188F KG190F KG192F KG192FD KG194FD KG194FD KG196FD
Max. Output(HP) 13/3600rpm 15/3600rpm 16/3600rpm 18/3600rpm 20/3600rpm 20/3600rpm 22/3600rpm
Displacement(cc) 389 418 448 460 500 500 550
Noise Level(at 7m) 73dB 73dB 73dB 73dB 80dB 80dB 80dB
Starting System Recoil Recoil Recoil Recoil/Electric
Type Force air-cooled,4-stroke
Ignition System Non-contact transistorized ignition(T.C.I.)
Fuel Tank (L) 25 12 12 25 25 25 25
Oil Capacity (L) 1.1 0.65 0.65 1.1 1.2 1.2 1.2
Package Dimension(LXWXH)mm 690*530*560 690*530*560 690*530*560 690*525*560 690*525*560 690*525*560 690*525*560
G.W (kg) 78 79 82 81 88 89 95
20FT/40HQ(SETS) 132/272 132/272 132/272 132/272 132/272 132/272 132/272
