Features
100% Copper Winding
Rare earth Permanent Magnet Alternator
Inverter Technology Stable Output
A4 Paper Size Weight only 10kg
Technical Date:
| GENSET Model | 550W | ||
| Rated frequency(Hz) | 50/60 | Engine model | 1E45f(2.0HP) |
| Rated viltage(V) | 230 | Engine type | 1 cylinder,2-stroke |
| Rated current(A) | 2.17 | Displacement(cc) | 63 |
| Rated speed(r/min) | 3300 | Fuel capacity(L) | 2.0 |
| Rated output(W) | 500 | Cont.running time(Hrs.) | 4.0 |
| Max.output(W) | 550 | Starting system | Recoil starter |
| Phase number | Single | Packing size LxWxH(mm） | 334x262x330 |
| Alternator type | 100% copper winding permanent magnet alternator | Net/Gross weight(kg) | 10.7/11.7 |
| Qty 20'GP/40'HQ(Sets) | 1030/2400 | ||
Comparison of traditional 950 gasoline genste VS inverter gasoline genset:
| Model | Traditional 950 Gasoline Geneset | NH800 Inverter Gasoline Genset | Contrast Result |
| Picture | |
||
| Rated Output | 600W/210V 1E45 | 800W/200V 1E45 | 200W more |
| Rated Frequency | 50Hz±5% | 50Hz±5% | Less frequency fluctuation |
| Volume | 380*320*320cm | 334*262*330cm | 2/5 less in volume |
| N.W（kg) | 17 | 11 | 6Kgs less in the weight |
| Ref.qty/40HQ（set) | 1600 | 2200 | 600 sets more in container loading |
| Fuel Consumption | 3000RPM,210V,600W,working condition 0.675/kw/H.L | 3000RPM,220V,800W,working condition 0.478/KW/H.L | 0.2L less in fuel consumption @KW/H |
